MSTAGE is an industrial mounting solution for MEX compact series beam expanders. This 4-axis manual translation stage contains a locking mechanism preserving the aligned position. It features sapphire contact pads determining long-lasting and smooth micro screw operation. There are four M6 x 0,25 micro screws for adjusting the platform’s pitch, yaw, Y, and Z-axis. Two micro screws control the platform’s pitch and Z-axis, while another two-control yaw and Y-axis. All of them can be adjusted with a 2 mm HEX screwdriver.

Main features

• Sapphire contact pads
• Platform’s locking mechanism
• Industrial design
• 4 axis fine adjustment
• Maximum load up to 1,5 kg

What’s in the box?

• Manual translation stage
• 3 x M4x0.7 10mm long screws for MEX mounting
