Calmar
![[ Calmar ]<br>Carmel X<Br>Compact Femtosecond Fiber Laser<br> 90fs Fiber laser with OEM/Scientific](/thum_img/mjct/goods_img3/f00a7a4c4f2ebc6afbab0aeafc133b71_water_4de0b559c44a49f5f544fca08f3bc282_c0_w500_h500.jpg)
)
Performance Advatage :
• Air cooled design : No chiller, for ease of installation and integration, reduced cost of ownership
• Compact laser head : 100x smaller than comparable Ti:sapphire lasers, portable, straight forward OEM integration
• Remote control/access : Full computer control, diagnostics and data logging capabilities for ease of OEM interface, field service and preventative maintenance
• All fiber based architecture : Inherent long term stability and reliability, instant turn on, push button or computer control
• High pulse energy : Up to 12.5 nJ at 780 nm, enabling a wide range of applications
• Sub 100 fs , l ow pedestal pulse shape : For the highest peak power and optimum nonlinear optical performance
• Excellent power stability : < 1% (RMS) over operating temperature range for consistent diagnostic signals
• Outstanding beam quality : M2 < 1.2, for optimum focused spot size and highest peak power density
• High Reliability : Designed for 24/7 hour operation with an expected lifetime of > 10,000 hrs
Specifications :
*모델명 클릭 시 데이터시트 확인가능
| Model Number | X-780/1550 | X-780 | X-1550 | X-1750 |
| Center Wavelength (nm) | 780 and 1550 | 780 | 1550 | 1750 |
| Pulse Width1 (fs) | < 90 | < 90 | < 90 | < 80 |
| Average Power (W) | 0.25 - 1.0, 0.5 - 2.0 | 0.25 - 1.0 | 0.5 - 2.5 | > 1.0 |
| Pulse Energy2 (nJ) | Up to 12.5, 25 | Up to 12.5 | Up to 25 | > 12.5 |
| Nominal Repetition Rate3 (MHz) | 50 - 80 | 50 - 80 | 50 - 80 | 80 |
| Polarization Extinction Ratio (dB) | 20, > 18 | > 20 | > 18 | > 20 |
| Beam Diameter (mm) | 1.3, 1.6 | 1.3 | 1.6 | 1.2 |
| Beam Quality (M2) | < 1.1 | < 1.1 | < 1.1 | < 1.2 |
| Cooling | Air Cooled | |||
| Laser Head Dimensions (cm) | 9(w) x 18(d) x 3.5(h) | |||
| Warm up time | 10 - 15 minutes (typical) | |||
1 A sech2 pulse shape (deconvolution factor of 0.65) is used to determine the pulse width from the second harmonic autocorrelation trace.
2 The absolute pulse energy will depend on the version and specified repetition rate.
3 For the 780, 1 W version, the repetition rate is 80 MHz, otherwise the repetition rate needs to be specified at the time of purchase.
